TThere are various ways you can create and manage a relationship between two tables. Once you have a primary key in one table, you can ask Microsoft Access to create and even configure a foreign key for you. You can simply indicate where the data will come from; that is, you must indicate the table that holds the primary key, select the field that holds the actual data to use. Microsoft Access would take care of configuring everything, or almost everything, behind the scenes for you. For this approach, you use a lookup field, which can be a combo box or a list box.

As done with the simple lookup, you can create a field whose data would be selected from a list. As opposed to an unbound lookup field whose values you can predict at the time you are creating a database, a bound lookup field is one whose values are not known in advance. The values for such a field become available as the database is growing./p>

To create a bound lookup field, you can open the table in Design View, set the data type of the field to Lookup Wizard... This would open the Lookup Wizard. Since you are creating a field that would get its data from another table or query, you must select the first radio button and click Next. Then follow the wizard.

1. The Occupancies table should still be opened in Design View.
   Click the empty field under DateOccupied, type RoomID
2. Set its Data Type to Lookup Wizard...


3. In the first page of the wizard, accept the first radio button and click Next
4. In the list of tables of the second page of the wizard, click Table: Rooms


5. Click Next
6. In the Available fields list of the third page of the wizard, double-click RoomNumber


7. Click Next
8. In the fourth page of the wizard, click Next
9. Accept the defaults in the fifth page of the wizard and click Next
10. Click Finish
11. When asked to save the table, click Yes
12. In the bottom section of the table, notice that the Field Size is set to Long Integer.
    Set the Caption to Room #
13. Save the table and switch it to Datasheet View

You can also create a lookup combo box using the Datasheet View of a table. To do this:

• To insert a new lookup fields between two columns, click the header of a column or an empty cell of the column that will succeed the new one. On the Ribbon, click Fields. In the Data Add & Delete section, click More Fields and click Lookup & Relationship

• To add a new lookup column at the end of the table, click Click to Add and click Lookup & Relationship

Any oh these actions would open the Lookup Wizard. Since you are creating a field that would get its data from another table or query, you must select the first radio button and click Next. Then follow the wizard.

When a column is a lookup field, if you don't like the way it behaves, you can reconfigure it. To do this:

• Click a column header or a cell under it. On the Ribbon, click Fields. In the Properties section, click Modify Lookups
• Right-click the header of the column and click Modify Lookups

1. On the Occupancies table, click the cell under Room #
2. On the Ribbon, click Fields if necessary.
   In the Add & Delete section, click the More Fields
3. Cllick Lookup & Relationship
4. In the first page of the Lookup Wizard, make sure the first radio button is selected and click Next
5. In the second page of the wizard, click the Queries radio button
6. In the list box, make sure Queries: Clerks is selected and click Next
7. In the third page of wizard, click the select all button


8. Click Next
9. In the fourth page of the wizard, click the arrow of the first combo box and select Employee Name


10. Click Next


11. In the fifth page of the wizard, view the list and click Next

12. In the sixth page of the wizard, read the text, accept to store the value in EmployeeID, and click Next


13. Click Next
14. Accept the suggested label and click Finish
15. While the new Field1 is still selected (if it is not, double-click it) type EmployeeID to rename the column and press Enter
16. On the table, click Click to Add
17. On the menu that appears, click Lookup & Relationship
18. In the first page of the Lookup Wizard, make sure the first radio button is selected and click Next
19. In the second page of the wizard, click Tables: Customers and click Next
20. In the third page of the wizard, click AccountNumber and click the Select One button
21. In the Available Fields, as FullName is selected, click the Select One button


22. Click Next
23. In the second page of the wizard, click the arrow of the first combo box and select AccountNumber
24. Click Next
25. In the third page of the wizard, accept the suggested label and click Finish
26. Switch the table to Design View
27. Move some fields and complete the table as follows:


    Field Name	Data Type	Caption	Field Size	Format
    OccupancyID (Primary Key)
    DateOccupied
    EmployeeID		Processed By
    CustomerID		Processed For
    RoomID		Room #
    RateApplied	Number	Rate Applied	Double	Fixed
    PhoneUse	Number	Phone Use	Double	Fixed
    InternetFee	Number	Internet Fee	Double	Fixed
    Notes	Memo



28. Save the table

When creating a bound lookup field, if you select only one column in the third page of the Lookup Wizard, a combo box would be created so the user can select the desired value. If the value you selected represents some type of insignificant number or character, when the user clicks the arrow of the combo box, the list of values that appear can be confusing and could lead the user to select the wrong one. Consider the following example:

When the user clicks the arrow of the combo box to select a room, this list does not specify what type of room the number represents. Any number could be for a bedroom, a studio, or a conference room. Because these numbers are vague, the user could select the wrong number and for example assign a conference room to a person who wants to rent a simple bedroom. There are various ways you can solve this type of problem. If no records have already been created and that involve that field, you can recreate the lookup field and make it display more than one column of values.

If you are creating or recreating a lookup field and you want it to display more than one column, in the third page of the wizard, you can double-click each of the desired values from the Available Fields list box:

Then continue with the wizard. When you finish with the wizard, Microsoft Access would take care of configuring the column. Sometimes you will not like the way Microsoft Access did the job. You can then modify it to your liking.

If the records exist already, you can simply modify the configuration of the lookup field. You have many options.

The configurations of the lookup field can be found in the Lookup section of the bottom part of the table in Design View. To configure a lookup field, click it in the top section of the table and, in the bottom section, click the Lookup tab. Here is an example:

To change a property, click it in the left section and change the value in the right section:

• Display Control: This allows you to specify how the field would display its value. The default is the combo box, which is suitable for most scenarios. If you want the values to appear in a list box on a form, you select the List Box option for this value. The other option is the text box
• Row Source Type: This specifies the type of list that contains the actual values. The default is Table/Query, which indicates that the values are stored in a table or a query. If the values are part of a constant list, such as one created from the second radio button of the first page of the wizard, you can set this property to Value List. The other option is Field List, which is mostly available if the list is programmatically created
• Row Source: This is the list of values. For a bound lookup field, this would be a SQL statement
• Bound Column: This is a number that specifies how many columns would connect with the primary key. The default value is 1. This should be the number of columns used in the primary key
• Column Count: This is an integer-based property that specifies the number of columns that would appear when the user clicks the arrow of the combo box on the field. If you select only one column from the Available Fields list of the second page of the wizard, this property would have a value of 1. Otherwise, if you want more columns, set this property accordingly
• Column Heads: This specifies whether the top section of the list would have a caption
• Column Widths: This specifies the width of each column of the lookup field when the list displays. The value of this property is made of sections separated by semi-colons. Each section represents the width of its corresponding column. In most cases, the first column, and that represents the foreign key, is not presented to the user and therefore should be set to 0. Each one of the other sections shows the desired width of the column and the columns can have different widths
• List Rows: This specifies the number of records that would be visible when the list appears. You should use a value between 4 and 16 (the default). A value higher than 16 is usually too long. Most programming environments (in fact as set in the Microsoft Windows operating system) use 8
• List Width: This is the total width of the list when it comes up. This should be the sum of numbers from the Column Widths property

1. In the top section of the table, click EmployeeID
2. In the bottom section of the table, click the Lookup tab, right-click Row Source and click Zoom... Notice how the SQL statement that was created


   SELECT 	[Clerks].[EmployeeID],
   	[Clerks].[EmployeeNumber],
   	[Clerks].[Employee Name]
   FROM Clerks
   ORDER BY [Employee Name];

3. Click Cancel to close the dialog box
4. Still in the Lookup tab, click Column Widths and change its value as follows: 0";0.75";1.25"
5. In the top section of the table, click RoomID
6. In the bottom section of the table, in the Lookup tab, click Row Source and click its ellipsis button
7. In the list of fields, click Type
8. Press Shift
9. Click Available and release Shift
10. Drag the group of columns and drop it on the right side of RoomNumber in the bottom part of the Query Builder:




11. On the Ribbon, click the Run button to preview the list
12. Close the Query Builder
13. When asked whether you want to save, click Yes
    Notice the SQL statement that was created


    SELECT 	Rooms.RoomID,
    	Rooms.RoomNumber,
    	Rooms.Type,
    	Rooms.Bed,
    	Rooms.Rate,
    	Rooms.Available
    FROM Rooms;

14. Make the following changes:
    Column Count:   6
    Column Heads:  Yes
    Column Widths: 0";0.65";0.9";0.7";0.5";0.8"
    List Rows:           8
    List Width:          3.55"
15. In the top section of the table, click CustomerID
16. In the Lookup section in the bottom part of the table, click Row Source and click its ellipsis button
17. Change the second field to Account #: AccountNumber
18. Change the third field to Customer Name: FullName
19. On the Ribbon, click the Close button
20. When asked whether you want to save, click Yes
    Notice the SQL statement that was created


    SELECT 	Customers.CustomerID,
    	Customers.AccountNumber AS [Account #],
    	Customers.FullName AS [Customer Name]
    FROM Customers;

21. Make the following changes:
    Column Widths: 0";0.65";1.35"
    List Rows:           8
22. Save the table and close it
23. Create a form for the Occupancies table and save it as Occupancies
24. Design it as you see fit. Here is an example:


25. Save the form and switch it to Form View


26. Enter the following records:


    Date Occupied	Processed By	Customer	Room #	Rate Applied	Phone Use	Internet Fee
    June 4, 2011	27049	294209	105	85.75	0.00	0.00
    June 5, 2011	28405	294209	105	85.75	5.35	0.00
    June 5, 2011	70429	608502	110	450.00	8.75	3.25
    June 6, 2011	70429	294209	105	85.75	0.00	0.00
    June 6, 2011	24095	208405	108	75.85	3.45	3.25
    June 7, 2011	28405	208405	108	75.85	2.65	0.00
    June 8, 2011	28405	208405	108	75.85	3.15	0.00
    June 9, 2011	27049	208405	108	75.85	1.95	0.00
    June 9, 2011	28405	284085	205	75.85	0.00	0.00
    June 10, 2011	24095	208405	108	75.85	5.50	0.00
    June 11, 2011	24095	629305	112	98.95	0.00	0.00
    June 12, 2011	70429	629305	112	98.85	0.00	0.00

27. Close the form
28. Open the Rooms form and change the records as follows:


    Room #	Type	Bed	Rate	Available
    104	Bedroom	Queen	79.95	Unchecked
    105	Bedroom	King	94.50	Checked
    106	Bedroom	Queen	79.95	Unchecked
    107	Bedroom	King	94.50	Checked
    108	Bedroom	Queen	79.95	Checked
    110	Conference		500.00	Unchecked
    112	Studio	King	112.95	Unchecked
    202	Studio	King	112.95	Checked
    203	Studio	Queen	104.50	Checked
    204	Bedroom	Double	115.95	Checked
    205	Bedroom	Queen	79.95	Unchecked
    206	Bedroom	King	94.50	Checked

29. Close the Rooms table
30. Re-open the Occupancies form in Form View and create the following new records:


    Date Occupied	Processed By	Customer	Room #	Rate Applied	Phone Use	Internet Fee
    July 18, 2011	28405	180204	105	94.50	0.00	3.25
    July 18, 2011	72947	660820	204	115.95	0.00	0.00
    July 18, 2011	28405	608208	206	94.50	0.00	3.25
    July 18, 2011	72947	204795	204	0.00	0.00	0.00
    July 18, 2011	28405	902840	203	104.50	0.00	0.00
    July 19, 2011	24095	180204	105	94.50	0.00	0.00
    July 19, 2011	24095	660820	204	115.95	0.00	0.00
    July 19, 2011	24095	608208	206	94.50	0.00	0.00
    July 19, 2011	24095	204795	204	0.00	0.00	0.00
    July 19, 2011	72947	902840	203	104.50	0.00	0.00

31. Close the form
32. Re-open the Occupancies form
33. Sort the record in ascending order from the Room # column
34. Filter the records to see only when Room 108 has been used
35. Filter the records to see only when the telephone has been used in a bedroom (the phone use different from 0)
36. Use Filter By Form to see only the transactions performed by employee number 28405
37. Close the Occupancies form

1. Create a blank database named Yugo National Bank2 and close the default table without saving it
2. Configure the database to display overlapping windows. Close and reopen the database
3. Start a new table in Design View and create the following columns:


   Field Name	Data Type	Field Size	Caption
   EmployeeID (Primary Key)	AutoNumber		Employee ID
   EmployeeNumber	Text	10	Employee #
   FirstName	Text	50	First Name
   LastName	Text	50	Last Name
   Title	Text	60
   CanCreateNewAccount	Yes/No
   WorkPhone	Text	40	Work Phone
   Extension	Number	Integer
   Address	Text	60
   City	Text	50
   State	Text	50
   ZIPCode	Text	30	ZIP Code
   Country	Text	50
   HourlySalary	Currency		Hourly Salary
   Notes	Memo

4. Save the table as Employees and close it
5. Create a form for the Employees table. Save the form as Employees and design it as you see fit


6. Close the table
7. Start a new table in Design View and create the following fields:


   Field Name	Data Type	Field Size	Caption
   AccountTypeID	AutoNumber		Account Type ID
   AccountType	Text	50	Account Type
   Description	Memo

8. Save the table as AccountTypes and close it
9. Create a form for the AccountTypes table. Save the form as AccountTypes and design it as you see fit. Here is an example:


10. Then Close it
11. Start a new table in Design View and create the following columns:


    Field Name	Data Type	Field Size	Caption
    CustomerID	AutoNumber		Customer ID
    DateCreated (Primary Key)	Date/Time		Date Created
    AccountNumber	Text	20	Account Number
    CustomerName	Text	50	Customer Name
    Address	Text	60
    City	Text	50
    State	Text	50
    ZIPCode	Number	Integer	ZIP Code
    Country	Text	50
    HomePhone	Text	40	Home Phone
    WorkPhone	Text	40	Work Phone
    Extension	Text	20
    EmailAddress	Hyperlink		Email Address
    Notes	Memo

12. Save the table as Customers and close it
13. Open the Customers table in Datasheet View
14. Use the Lookup Wizard to add a column between the Date Created and the Account Number columns. The values of that column will come from the Employees table, including the following columns: EmployeeNumber, FirstName, LastName, Title, and CanCreateNewAccount
15. Save and close the table
16. Open the Customers table in Design View
17. Add a field between the Account Number and the Customer Name fields. Name it AccountTypeID and set its Data Type to Lookup Wizard...
18. Using the wizard, select the values from the AccountTypes table, including the AccountType column
19. Still in Design View, change the names and captions of the new columns as follows:


    Field Name	Data Type	Field Size	Caption
    CustomerID	AutoNumber		Customer ID
    DateCreated (Primary Key)	Date/Time		Date Created
    EmployeeID	Number		Created By
    AccountNumber	Text	20	Account Number
    AccountTypeID	Number		Account Type
    CustomerName	Text	50	Customer Name
    Address	Text	60
    City	Text	50
    State	Text	50
    ZIPCode	Number	Integer	ZIP Code
    Country	Text	50
    HomePhone	Text	40	Home Phone
    WorkPhone	Text	40	Work Phone
    Extension	Text	20
    EmailAddress	Hyperlink		Email Address
    Notes	Memo

20. Start a new table in Design View create its columns as follows:


    Field Name	Data Type	Field Size	Caption
    TransactionTypeID	AutoNumber	Long Integer	Transaction Type ID
    TransactionType	Text	50	Transaction Type
    Description	Memo

21. Save the table as TransactionTypes and close it
22. Create a form for the TransactionTypes table. Save the form as TransactionTypes and design it as you see fit. Here is an example:


23. Close the form
24. Start a new table in Design View create its columns as follows:


    Field Name	Data Type	Field Size	Caption
    ChargeReasonID	AutoNumber	Long Integer	Charge Reason ID
    ChargeReason	Text	50	Charge Reason
    Description	Memo

25. Save the table as ChargeReasons and close it
26. Create a form for the ChargeReasons table. Save the form as ChargeReasons and design it as you see fit
27. Close the form
28. Start a new table in Design View and create the following columns:


    Field Name	Data Type	Field Size	Caption
    TransactionID (Primary Key)	AutoNumber		Transaction ID
    EmployeeID	Number	Long Integer	Processed By
    CustomerID	Number	Long Integer	Processed For
    TransactionTypeID	Number	Long Integer	Transaction Type
    TransactionDate	Date/Time		Transaction Date
    TransactionNumber	Number		Transaction Number
    DepositAmount	Currency		Deposit
    WithdrawalAmount	Currency		Withdrawal
    ServiceCharge	Currency		Service Charge
    ChargeReasonID	Number	Long Integer	Charge Reason
    Notes	Memo

29. Save the table as Transactions
30. Set the Data Type of EmployeeID to Lookup Wizard. Use the wizard to select the following columns of the Employees table: EmployeeNumber, LastName, and FirstName
31. Set the Data Type of CustomerID to Lookup Wizard. Use the wizard to select the AccountNumber and the CustomerName columns of the Customers table
32. Set the Data Type of TransactionTypeID to Lookup Wizard. Use the wizard to select the TransactionType field of the TransactionTypes table
33. Set the Data Type of ChargeReasonID to Lookup Wizard. Use the wizard to select the ChargeReason field of the ChargeReasons table
34. Close the table

1. Create a blank database named Watts A Loan2
2. Configure it to display overlapping windows

• Create a blank database named World Statistics2

1. Create a new blank database and name it US Senate2
2. Do some research on the Internet or use a book that can help you. Make a list of the names of states in the United States. You should get the name of a state and its abbreviation
3. Start a new table in the Design View and create the following fields:


   Field Name	Data Type	Field Size	Caption
   StateID	AutoNumber		State ID
   StateAbbreviation	Text	50	State Abbreviation
   StateName	Text	50	State Name
   WebSite	Text	100	Web Site
   Capital	Text	50
   Governor	Text	50

4. Save the table as States
5. Start a new table in the Design View and create the following fields:


   Field Name	Data Type	Field Size	Caption
   PartyID	AutoNumber		Party ID
   PartyName	Text	50	Party Name

6. Save the table as Political Parties
7. Start a new table in the Design View and create the following fields:


   Field Name	Data Type	Field Size	Caption
   SenatorID	AutoNumber		Senator ID
   SenatorName	Text	50	Senator Name
   SeatingStatus	Text	50	Seating Status
   Gender	Text	30
   StateID	Number	Long Integer
   Race	Text	40
   Religion	Text	50
   YearElected	Number	Integer	Year Elected
   PartyID	Number	Long Integer
   DCAddress	Text	255	DC Address
   DCOfficePhoneNumber	Text	40	Office Phone #
   WebSite	Hyperlink		Web Site
   LocalAddress1	Text		Local Address 1
   LocalAddress2	Text		Local Address 2
   LocalAddress3	Text		Local Address 3
   LocalAddress4	Text		Local Address 4
   Pictures	Attachment
   Biography	Memo

8. Save the table as Senators
9. Use the Lookup Wizard on the SeatingStatus column to create a list of the status. The options will be Active, Retired, Removed, and Deceased
10. Use the Lookup Wizard on the Gender column to create a list of the genders. The options will be Male, Female, and Unknown. Set the Default Value to "Unknown"
11. Use the Lookup Wizard on the State to link the list of states from the States table using the state abbreviation column
12. Use the Lookup Wizard on the Race column to create a list of the races. The options will be Black, White, Native American, Hispanic, Asian, Other
13. Use the Lookup Wizard on the Religion to create a list of the religions. The options will be Catholic, Muslim, Jewish, Baptist, Presbyterian, Atheist, Other
14. Use the Lookup Wizard on the PartyID to create a link of to the Political Parties table using the Party Name column
15. Save and close the table
16. Create a form for the Senators table. Save the form as Senator
17. Go to http://www.senate.gov
18. Get the information about each senator and populate the Senators form with that information
